PQWT-M400

Compare

PQWT-M400.400M Mobile Water Detector

PQWT M400 Underground Water Detector and Water Survey Equipment ...

PQWT-M400.400M mobile water detector is based on the Earth’s electromagnetic field as the field source, based on the difference in the conductivity of different underground geological structures, and by studying the variation law of the electric field components at different frequencies to study the geological structure and changes, to find groundwater resources by scientific method. Changes in geological structure are displayed in real-time through multiple curves. Automatic form mapping geological profile by one key operate easily, get rid of complicated computer graphics. The site can quickly understand the geological structure through the automatic mapping curve and profile, and analyze specific information such as aquifers, fractures, faults, and caves. The instrument is widely used in the rapid analysis of geological structure changes in different terrains such as plains, hills, mountains, plateaus, and basins to determine well locations, aquifers, and aquifer depth

Features

1. No need to register

2. No need network, no need traffic

3. Automatically draw geological profile map

4. Suitable for various terrain exploration

5. Expert remote assistance to find location

6. No experience person can operate in 5 minutes

7. Two years warranty.

Technical Specification

Model PQWT-M400
Depth 400 Meters
Frequency Single, Triple, 48frequency
Measurement data unit electric field component of different frequencies of the earth electromagnetic field ΔVs (mV)
Channel 8
System PQWT
LCD Industrial 7-inch HD touch screen
Units of Measurement △Vs(mV)
Measurement Range 0mV-200mV
Display LED indicator
A/D conversion 8-bit 1Msps
Input impedance ≥10MΩ
Relative humidity ≤85%
Power consumption about 1W
Working environment temperature -20°C ~ +50°C
Power Supply Battery Model #18650; 3000mAh Rechargeable lithium battery
